SUGA Test Instruments manufactures world-class weather meters, accelerated corrosion instruments and instrumental colour appearance product solutions.
Conforms to JASO M 609:2024
This is a combined cyclic corrosion test instrument capable of performing salt spray, dry, humidity, and outside air intake tests either independently or in combination.
In addition to ISO, IEC, SAE, and JIS standards, it conforms to the latest automotive standard, JASO M 609:2024 (Japanese Automobile Standard) salt spray methods A, B, and C, published in 2024. Salt shower and salt immersion methods are available as options.
Significantly improved durability with keeping the same spray performance.
The new model can test 64 test specimens. 6 more test specimens are installed compared to the previous model (CYP-90). The system is designed to ensure uniform salt spray distribution for all test specimens by natural fall.
Achieved over 30% water conservation compared to the previous model (CYP-90) by improved rinsing methods.*
*Based on calculations assuming ISO 14993 testing.The solution tank and air saturator are integrated on the right side to improve workability such as solution replenishment and cleaning.
The air barrier board suppresses the salt concentration fluctuations and pH variation in the solution tank.
ISO/IEC 17025** accredited calibration certification can be issued for spray pressure gauge, temperature sensor, air saturator sensor. Users can handle the attachment and detachment of the calibration devices by themselves.
**ISO/IEC 17025：General requirements for the competence of testing and calibration laboratories
